agriculture drone joyance

Name: agriculture drone joyance
Brand: Innovaciones Globales
SKU: 196399125011003_264280950
Price: 16520.0 USD
Availability: InStock

Innovaciones Globales

Capacity agricultural drone sprayer

Model Number JT30L-606 JT10L-606 JT20L-606

Variantes de producto

China 20L intelligent flight agriculture drone UAV sprayer drone JT20L-606 Agricultural dron for farm

Details of agriculture drone

Joyance Tech provides OEM/ODM services for agriculture drones.

No	Technical parameter	JT10L-606	JT20L-606
1	Pesticide load	10 liters	20 liters
2	Self weight	10.5 kg	18.5 kg
3	Take-off weight	23 kg	44 kg
4	Fly time	10~15 min	10~15 min
5	Spraying efficiency	5~6 hectares/hour	9~11 hectares/hour
6	Spray width	5~6 m	7~8 m
7	Spray speed	0~8 m/s	0~10 m/s
8	Nozzle	2 centrifugal nozzles	4 centrifugal nozzles
9	Battery	2 pcs * 6S 17000 mAh	2 pcs * 6S 23000 mAh
10	Spray flow	1~ 1.5 L/min	2.5~ 3 L/min
11	Flying radius	1500 m	1500 m
12	Flying height	0~30 m	0~30 m
13	Wind resistance	10 m/s	10 m/s
14	Spread size (m)	1.3 * 1.3 * 0.45 m	1.95 1.95 0.57 m
15	Folded size (m)	0.6 * 0.6 * 0.51 m	0.7 * 0.7 *0.8 m
16	Aluminum box size/weight	736765 cm / 50 kgs	758595 cm / 90 kgs

Agriculture Drone Applications

Plantations: rice, corn, sugar cane, soybean, flower, coffee, vegetables, fruit trees, etc.

Chemical/fertilizer use: liquid pesticide, herbicide, solid fertilizer/granule fertilizer, fungicide, insecticide, seed, biological ball, etc.

OYANCE agriculture sprayer drones have been widely used for crop protection, mosquito control, and public disinfection.

Advantages of Joyance sprayer drones

Joyance

Others

Carbon fiber tube: 40 mm of diameter; 2mm thickness carbon fiber tube.

Other brands (right side)：Less diameter, or same diameter, but only 1mm thickness carbon fiber tube.

Joyance：3mm thickness centre plate.

Other brands：1mm thickness centre plate

Joyance: Aviation aluminum folding joints,also one-piece designed, rust-proof, fasten connection and very strong, more safer for heavy duty work.

Others brands: spring designed, easy to be damaged, short life. The thread will be loosen after working for some time,it’s not stable enough to fly.

Joyance: This model sprayer drone has 4 centrifugal nozzles which has a better atomization and penetration effect :

● 50-200 um droplet diameter

● Spray degree: 170 ● Not easy to block. ● More suitable for spraying in orchards, crops, vegetables, rice,corn, etc.

Joyance agriculture sprayer drone with granule spreader can spread solid fertilizers, granule fertilizer, seeds, sows, feed and so on. Besides it can be switched spraying system and spreading system by one-key. Also Sprayer & Spreader 2 in 1 drone = save lots of cost.
