axis rc agricultural sprayer drone farming small spray uav dron price 30kg

Name: axis rc agricultural sprayer drone farming small spray uav dron price 30kg
Brand: Innovaciones Globales
SKU: 196397396011003_263235282
Price: 13663.61 USD
Availability: InStock

Innovaciones Globales

Capacity 20L 30l

Variantes de producto

Product Description

Details Images

Excellent Spraying Performance

30L tank for spraying Efficiency of FP300 has been increased to 14.6 ha/hr.
Auto pressure relief valve.
High pressure nozzle ensures no drifting Support centrifugal nozzle. Powder agrochemical will not block the pipe.
Full-range continuous level meter. The real-time level will be shown on the APP.
nozzles
m spraying width
L/min flow rate

Effectiveness and Evenness of Spreading

45L container，7m spreading range
Air jet spreading system
Spread evenly, and no harm to the seeds
IP67, waterproof and no corrosion
No blocking anymore, and water washable
Real-time weight monitoring
Overloading is prevented

Easy and efficient

3 operation modes including AB Points, full autonomous and manual mode.
Field surveying modes: RTK T-marker, drone surveying and selecting on the map.
High-definition touch-screen RC which can work for 6-8 hours continuously High brightness; clearly visible even in the sunny
outdoor environment.
Border line scanning function will generate routes automatically. No omission of spray/spreading
Equipped with FPV auxiliary lights and landing light Working at night becomes easy and safe
The battery can be fully charged in 10 mins. 2 batteries and 1 charger are enough for non-stop operation

A Durable Drone to Meet Your Expectation

High strength navigational aluminum frame
Critical components are enclosed
Keep dust and agrochemical outside
Battery life: more than 1000 cycles

Smart assist function, ensure the flight safety

Detect the obstacles from 40m away and circumvent obstacles automatically
The terrain following radar and obstacle avoidance radars providing a safer operation experience
A front and a rear 720p HD FPVs The rear one can face downwards enabling a real-time view of the ground

A worry-free high-tech agricultural machine

A worry-free high-tech agricultural machine
IP67 module-level protection
Modular design The consumable parts can be easily replaced by users

Specification

FP Series Parameter Comparison			_{FP Series Parameter Comparison}	value
Models	FP300	FP200
Features
GPS	√	√
RTK	√	√
FPV	Front and rear FPV Cameras	Front and rear FPV Cameras
Obstacle Avoidance	Front&Rear Obstacle Avoidance	Front&Rear Obstacle Avoidance
Terrain Following	5 beams for detection	5 beams for detection
Manual Flight	√	√
A-B Point	√	√
Autonomous Flight	√	√
Basic Specs			Key Selling Points	High Productivity
Wheelbase	1970 mm	1945 mm
Dimension (Unfolded)	25151650788 mm	23401650785 mm
Dimension (Folded)	10401010788 mm	11151070785 mm
Spray Widths (depends on the crop)	6～8 m	5～8 m
Weight(incld. battery)	40.6 kg	37.2 kg
Max Take-off Weight (at Sea Level)	77.8 kg	63.6 kg
Battery	30000mAh, 51.8V	30000mAh, 51.8V
Flight Specs			Type	Farm Equipment
Hover	＞20min(unloaded) ＞8min(loaded)	unloaded（spray）25min loaded（spray）12min
Max Speed	8m/s(GPS mode)	8m/s(GPS mode)
Operation Altitude	1.5~3m	1.5~2.5m
Positioning Accuracy with strong GNSS signal, RTK enabled	Horizontal ± 10cm Vertical ± 10cm	Horizontal ± 10cm Vertical ± 10cm
Obstacle Avoidance detection distance	Forward or backward detection depending on the flight direction	Forward or backward detection depending on the flight direction
Autonomous Circumvention	√	√
Spraying Specs
Tank Capacity	30L	20L
Nozzle Type	High-pressure flat fan nozzle Support to switch to centrifugal nozzle	High-pressure flat fan nozzle Support to switch to centrifugal nozzle
Nozzle Model	11015VS	11015VS
Nozzle Quantity	12	8
Max Spray Rate	8.1L/min	5.4L/min
Spray Range	6~8m	5~8m
Spreading Specs
Container Size	45L	35L
Loading Method	Rolling Feeder	Rolling Feeder
Spreading Method	High Speed and Focused Airflow	High Speed and Focused Airflow
Loading Speed	50L/min	50L/min
Spread Range	5~7m	5~7m
