Products Description

JOYANCE drones have been widely using for crop protection, mosquito control, and public disinfection.

Plantations: rice, corn, sugar cane, soybean, flower, coffee, vegetables, banana, fruit trees.

Chemical use: liquid pesticide,herbicide, foliar fertilizer, fungicide, insecticides, etc. Sprayer Drone adopts low volume technology, the pesticide droplet diameter is only 50~200um, has better atomization and penetration effect, save 90% water and 20% pesticides use.

High Efficiency: One drone can cover 50~70 hectares field per day. Compared with plane, tractor and hand-held sprayers, drone sprayer is more efficient, reduce water & pesticides use, has less drift, keeps people away from heat-stroke and chemical poisoning.

Product Parameter

Model			JT10L-404QC	JT16L-404QC	JT30L-606
Pesticide Tank			10L	16L	30L
Net Weight			13kg	18kg	27.5kg
Take-off Weight			27kg	40kg	67KG
Flying Time			10~15min	10~15min	10~15min
Flying Radius			0~1500m	0~1500m	0~1500m
Flying Height			0~30m	0~30m	0~30m
Flying Speed			0~12m/s	0~12m/s	0~12m/s
Work Temperature			-10~70°C	-10~70°C	-10~70°C
Work Humidity			0~90%	0~90%	0~90%
Spray Speed			0~8m/s	0~8m/s	0~8m/s
Spray Width/Nozzle No.			>3.5~5.5m / 4 Nozzles	>4~6m / 8 Nozzles	>8~10m / 10 Nozzles
Spray Flow			1~1.5L/min	2~2.5L/min	3.5~4L/min
Spray Efficiency			5~7Ha/Hr	8~10Ha/Hr	12~15Ha/Hr
Flying Downward Airflow			4~15m/s	4~15m/s	4~15m/s
Wind Resistance			10m/s	10m/s	10m/s
Machine Size	Spread Size	W1.14m x L1.12m x H0.58m	W1.40m x L1.35m x H0.7m	W2.2m x L1.85m x H0.8m
Machine Size		Folded Size	W0.82m x L0.64m x H0.58m	W0.88m x L0.77m x H0.7m	W1.25m x L0.9m x H0.8m
Power System	Motor	Brushless	Brushless	Brushless
		Propeller	Carbon Fiber	Carbon Fiber	Carbon Fiber
		ESC	Rapid Throttle Response	Rapid Throttle Response	Rapid Throttle Response
Flight Control			K++ V2	K++ V2	K++ V2
Remote Controller			Joyance Datalink H12 RC	Joyance Datalink H12 RC	Joyance Datalink H12 RC
Battery / Quantity			14S 10000mAh / 1pc	14S 20000mAh / 1pc	14S 28000mAh / 1pc
Adapter + Charger			Dual-Channel Charger 2400W	Dual-Channel Charger 3000W	Dual-Channel Charger 3000W
Aluminum box size / weight			89268cm / 50kg	989275cm / 65kg	*15410994cm / 100kg*
Toolkit			Maintenance/Repair Tools	Maintenance/Repair Tools	Maintenance/Repair Tools

Product Feature

1.H12 intergrated remote controller

Equipped with ground station app,image transmission,one key transformation to image,three-proofing camera with led light to work at night.Drone flight is more safer.

2.

Fashionable and Exclusive appearance, the waterproof of whole drone is IP56, sprayer drone is suitable for working in the rain.

3.

The front-end control system and the back-end power supply system are independent, reasonable wiring, avoid electromagnetic interference, also easy to repair and replace.

4.Nozzle and Spray boom

(1) High pressure nozzle: spray width: 4-6m; Less drift; has automatic relief valve. No miss spray or re-spray; Good spraying effect. (2) Spray boom: soft connection designed, not easy to damage.
